IJWMT Vol.8, No.1, Jan. 2018

Simulation of Rectangular Ring Micro-Strip Patch Antenna to Enhance Impedance Bandwidth for UWB Wireless Applications

Full Text (PDF, 761KB), PP.34-41


Views:61   Downloads:3

Author(s)

Anant Raj Mishra, Ankit Gambhir, Rajeev Arya

Index Terms

Ultra Wideband (UWB);Ring Micro-strip Patch Antenna;Impedance Bandwidth; Radiation Efficiency;Gain

Abstract

In this paper, simulation of rectangular ring micro-strip patch antenna for ultra wideband (UWB) wireless applications is done. The attractiveness of this antenna is that it employs solo patch that makes it easy to fabricate and economical as well. It also mitigates the issue of misalignment. By making use of matching rectangular strips, impedance bandwidth enhancement is also attained. At centre frequency return loss is not more than -10dB. It demonstrates superior radiation characteristics and reasonable gain in the whole operating band. In the designing of proposed antenna, micro-strip feeding is used for power supply purpose. CST Microwave studio suit 10 is used for the simulation purpose of the proposed antenna, which is a 3D electromagnetic field tool for simulation of electromagnetic field in all frequency bands. After simulation of proposed antenna, enhancement in impedance bandwidth of 20.60%, frequency range of 1.8533 GHz, radiation efficiency of 92.51%, and gain of 3.765dbi are obtained.

Cite This Paper

Anant Raj Mishra, Ankit Gambhir, Rajeev Arya," Simulation of Rectangular Ring Micro-Strip Patch Antenna to Enhance Impedance Bandwidth for UWB Wireless Applications", International Journal of Wireless and Microwave Technologies(IJWMT), Vol.8, No.1, pp. 34-41, 2018.DOI: 10.5815/ijwmt.2018.01.04

Reference

[1]Amit Kumar, UtkarshBesaria and Rjeev Gupta, ‘Four-Element Triangular Wideband Dielectric Resonator Antenna excited by a Coaxial Probe’,  IOSR Journal of Electronics and.  Volume 6, Issue 4, pp. 1-6, May. - Jun. 2013.

[2]Yong Mei Pan, Shao Yong Zheng, BinJie Hu,  ‘Design of Dual-Band Omnidirectional Cylindrical Dielectric Resonator Antenna’, IEEE antennae and wireless propagation letters, vol. 13, pp. 710-713, 2014.

[3]Xiaosheng Fang, Kwok Wa Leung, Eng Hock Lim,‘Singly-Fed Dual-Band Circularly Polarized Dielectric Resonator Antenna’, IEEE antennae and wireless propagation letters, vol.  13, pp. 995- 998, 2014.

[4]FizzaKhatoon, Amit Kumar, Nidhi Vats, ‘Stack of Four Element Triangular Dielectric Resonator Antenna Excited by Coaxial Probe’, Volume 4, Issue 5, pp. 287-290, May 2014.

[5]Nidhi, Amit Kumar, FizzaKhatoon, ‘Stacked Equilateral Triangular Dielectric Resonator Antenna Excited With Coaxial Feeding’, Volume 9, Issue 3, Ver. VI, pp. 1-7, May - Jun. 2014.

[6]Yong-Mei Pan, Kwok Wa Leung, KaiLu, ‘Compact Quasi-Isotropic Dielectric Resonator Antenna With Small Ground Plane’, IEEE transactions on antennae and propagation, vol. 62,  no. 2, pp. 577-585, February 2014.

[7]A.H. Majeed, A. S. Abdullah, F. Elmegri, K. H. Sayidmarie, R. A. Abd-Alhameed, and J. M. Noras, ‘Aperture-Coupled  Asymmetric Dielectric Resonators Antenna for Wideband Applications’, IEEE antennae and wireless propagation letters, vol. 13, pp. 927-930,  2014.

[8]Meng Zhang, Bin Li, XinLv, ‘Cross-Slot-Coupled Wide Dual-Band Circularly Polarized  Rectangular  Dielectric Resonator Antenna’, IEEE antennae and wireless propagation letters,  vol. 13, pp. 532-535, 2014.

[9]Ranjana Singh, Amit Kumar, ‘Multi-segment cylindrical dielectric resonator antenna’, Volume 5, Issue 5, pp. 27-35, May 2014.

[10]Vinay Kumar Prajapati, Amit Kumar,  Anamika,  ‘An Array of Four Cylindrical Dielectric Resonator Antenna for Wideband Monopole Like Radiation’, International Journal of Engineering Research & Technology (IJERT), Vol. 3 Issue 5, pp. 2092-2096, May 2014

[11]Sheikh DobirHossain, K. M. AbdusSobahan, Md. Khalid Hossain, Md. MasudAhamedAkash, Rebeka Sultana, Md. MasumBillah. A Rectangular Micro-strip Patch Antenna for Wireless Communications Operates in Dual Band. IJWMT.PP.35-44, 2016.05.04.

[12]T.Jayanthy, I.RexilineSheeba.Design and Analysis of Biquad Patch Antenna with Different Hard Substrates for UWB Applications.PP.58-66, IJWMT.2017.03.06.

[13]A. Rashidian, K. Forooraghi and M. T. Aligodarz. Investigations On Two-Segment Dielectric Resonator Antennas. Microwave and Optical TechnicalLetters.Vol. 45. PP. 533-537. June.2005.

[14]P. Rezaei, M. Hakkak, and K. Forooraghi.Design of Wide-Band DielectricResonator Antenna with a Two-Segment Structure.Progress InElectromagnetics Research PIER 66. PP. 111-124. 2006.

[15]Q. Rao, T. A. Denidni and A. R. Sebak.Broadband Compact Stacked T-Shaped DRA with Equilateral-Triangle Cross Sections.IEEE Microwave WirelessComp. Letter. Vol. 16.PP. 7-9. January 2006.
