IJWMT Vol.5, No.1, Mar. 2015

Matlab-Based Computer-Aided-Design Algorithm for Designing Stepped-Impedance Resonator Low-Pass Filters in Microstrip Technology

Full Text (PDF, 597KB), PP.1-20


Views:73   Downloads:1

Author(s)

Luv Tomar, Saurabh Gupta, Raghuvir Tomar, Prakash Bhartia

Index Terms

Microstrip;Filter;CAD;MATLAB;MIC

Abstract

An accurate MATLAB-based CAD algorithm for quickly designing microstrip-based stepped-impedance resonator (SIR) low-pass filter is reported. The algorithm uses a circuit-theory approach to implement speedy computations, compared to the time-consuming computations involved in using electromagnetic theory.
The accuracy of the proposed algorithm is verified for two widely-different practical examples in the 0-4GHz frequency range, against results obtained using Ansoft/Ansys circuit simulation tool, and against results obtained using the 3D electromagnetic simulator HFSS. The agreement among the three sets of data is seen to be excellent for most cases, and is found to be practically acceptable in the worst-case.

Cite This Paper

Luv Tomar, Saurabh Gupta, Raghuvir Tomar, Prakash Bhartia,"Matlab-Based Computer-Aided-Design Algorithm for Designing Stepped-Impedance Resonator Low-Pass Filters in Microstrip Technology", IJWMT, vol.5, no.1, pp.1-20, 2015.DOI: 10.5815/ijwmt.2015.01.01

Reference

[1]http://mathworks.com/

[2]Atia JO. Electronics and circuit analysis using MATLAB.Washington D.C.: CRC Press; 1999.

[3]Niehenke EC, Pucel RA, Bahl IJ. Microwave and millimeter-wave integrated circuits. IEEE T-MTT 2002;50:846-57.

[4]Bahl IJ, Bhartia P. Microwave solid state circuit design. New Jersey: Wiley; 2003.

[5]Ahn H. Asymmetric passive components in Microwave Integrated Circuits. New Jersey: Wiley; 2006.

[6]Ezzeddine AK. Advances in microwave and millimeter-wave circuits. IEEE Radio Sci Conf 2007; 1-8.

[7]Tomar RS, Pramanick P, Bhartia P. The use of 3D electromagnetic simulation tools in the design of Microwave Integrated Circuits: an accuracy assessment. IEEE Int. Conf. Microwaves Commun Antennas Electronic Systems (COMCAS) 2009; 1-3.

[8]Pozar DM. Microwave engineering. 4th ed. New Delhi: Wiley-India; 2010.

[9]Maloratsky LG. Passive RF and microwave integrated circuits. Amsterdam: Elsevier; 2010.

[10]www.microwaves101.com

[11]Marzuki A, Rahim AIA, Loulou M. Advances in Monolithic Microwave Integrated Circuits for wireless systems: modeling and design technologies. Hershey: IGI Global; 2011.

[12]Singh P, Tomar R. The use of defected ground structures in designing microstrip filters with enhanced performance characteristics. Conf. Electronics Telecommunication Computers (CETC) 2013; 1-4.

[13]Agrawal A, Singhal PK, Jain A. Design and optimization of a microstrip patch antenna for increased bandwidth. Int J Microwave and Wireless Technologies 2013; 5: 529-35.

[14]Nesic DA, Kolundzija BM, Tosic DV, Jeremic DS. Low pass filter with deep and wide stop band and controllable rejection bandwidth. Int J Microwave and Wireless Technologies 2014; 6.

[15]http://www.ansys.com
