IJWMT Vol.6, No.5, Sep. 2016

Compact UWB BPF with a Tunable Notched Band based on Triple-mode HMSIW Resonator

Full Text (PDF, 657KB), PP.1-9


Views:83   Downloads:3

Author(s)

Chunxia Zhou, Peipei Guo, Wen Wu

Index Terms

Filter;Half-mode substrate integrated waveguide (HMSIW);Tunable notch;Ultra-wideband (UWB)

Abstract

A novel triple-mode resonator based on the half-mode substrate integrated waveguide (HMSIW) structure is proposed to design the ultra-wideband (UWB) filters. The UWB filter topology is given by analyzing the resonant frequencies of the three modes and the signs of the coupling between the three modes and the input/output ports. With the filter synthesis method, a triple-mode UWB filter with passband from 3.1-10.6 GHz is effectively realized with two transmission zeros at the upper stopband. To block the existing undesired narrowband radio signals in FCC UWB range, a notched band can be easily generated and controlled by a loaded stub-capacitor. For demonstration, an UWB filter with a tunable notched band from 3.7 to 7.7 GHz and compact size is designed and fabricated. Both simulated and measured results indicate that the proposed new filter has the properties of wide tuning range of the notched band and sharp roll off.

Cite This Paper

Chunxia Zhou, Peipei Guo, Wen Wu,"Compact UWB BPF with a Tunable Notched Band based on Triple-mode HMSIW Resonator", International Journal of Wireless and Microwave Technologies(IJWMT), Vol.6, No.5, pp.1-9, 2016.DOI: 10.5815/ijwmt.2016.05.01

Reference

[1]Chen, X.; Hong, W.; Cui, T.; Chen, J.; Wu, K.: Substrate integrated waveguide linear phase filter, IEEE Microwave Wireless Compon. Lett., 15 (2005), 787–789.

[2]Wu, L.; Zhou, X.; Zhou, L.; Yin, W.; Mao, J.: A substrate integrated evanescent-mode waveguide filter with nonresonating node in low temperature co-fired ceramic, IEEE Trans. Microw. Theory Tech., 58 (2010), 2654-2662.

[3]Hu, G.; Liu, C.; Yan, L.; Huang, K; Menzel, W: Novel dual mode substrate integrated waveguide band-pass filters. J. Electromagn. Waves Appl. 24 (2010), 1661–1672.

[4]Hao, Z.; Hong, W; Chen, J; Chen, X; Wu, K: Compact super-wide bandpass substrate integrated waveguide filters, IEEE Trans. Microwave Theory Tech., 53 (2005), 2968–2977.

[5]Wu, L.; Zhou, X; Yin, W.: Ultra-wideband bandpass filter using half-mode T-septum substrate integrated waveguide with electromagnetic bandgap structures, Microw. Opt. Technol. Lett., 51 (2009), 1751–1755.

[6]Chu, H; Shi, X.: Compact Ultra-Wideband Bandpass Filter Based on SIW and DGS Technology with a Notch Band. J. Electromagn. Waves Appl. 25 (2012), 589–596.

[7]Chen, R.; Wong, S.; Zhu, L.; Chu, Q.: Wideband Bandpass Filter Using U-Slotted Substrate Integrated Waveguide (SIW) Cavities, IEEE Microw. Wirel. Compon. Lett., 25 (2015), 1– 3.

[8]Huang, L.; Cha, H.: Compact Ridged Half-Mode Substrate Integrated Waveguide Bandpass Filter, IEEE Microw. Wirel. Compon. Lett., 25 (2015), 223– 225.

[9]Zhu, L.; Sun, S.: Ultra-wideband (UWB) bandpass filters using multiple-mode resonator, IEEE Microw. Wirel. Compon. Lett., 15 (2005), 796– 798.

[10]Chun, Y.; Shaman, H.; Hong, J.: Switchable embedded notch structure for UWB bandpass filters, IEEE Microw. Wirel. Compon. Lett., 18 (2008), 590–592.

[11]Pankaj, S.; Ishita, R.; Sharmili, A.: A band notch UWB bandpass filter using dual-stub-loaded multimode resonator with embedded spiral resonator. Int. J. Microw. Wirel. Technol., 6 (2014), 161–166.

[12]Pirani, S.; Nourinia, J.; Ghobadi, C.: Band-notched UWB BPF design using parasitic coupled line, IEEE Microw. Wirel. Compon. Lett., 20 (2010), 444–446.

[13]Luo, X.; Ma, J.; Ma, K.; Yeo, K.: Compact UWB bandpass filter with ultra narrow notched band, IEEE Microw. Wirel. Compon. Lett., 20 (2010), 145–147.

[14]Gholamreza, K.; Farnaz, K.; Hesam, S.: Compact UWB BPF using slotted resonator with an independently controllable notched band. Int. J. Microw. Wirel. Technol., 8 (2016), 25–31.

[15]Wei, F.; Wu, Q.; Shi, X.; Chen, L.: Compact UWB bandpass filter with dual notched bands based on SCRLH resonator, IEEE Microw. Wireless Compon. Lett., 21 (2011), 28–30.

[16]Wong, S.; Zhu, L.: Implementation of compact UWB bandpass filter with a notch-band, IEEE Microw. Wireless Compon. Lett., 18 (2008), 10–12.

[17]Kim, C.; Chang, K.: Ultra-wideband (UWB) ring resonator bandpass filter with a notched band, IEEE Microw. Wirel. Compon. Lett., 21 (2011), 206–208.

[18]Wu, Z.; Shim, Y.; Pistono, E.; Mina, R.: Miniaturized UWB Filters Integrated With Tunable Notch Filters Using a Silicon-Based Integrated Passive Device Technology, IEEE Trans. Microw. Theory Tech., 60 (2012), 518–527.

[19]Nosrati, M.; Vahabisani, N.; Daneshmand, M.: Compact MEMS-Based Ultrawide-Band CPW Band-Pass Filters With Single/Double Tunable Notch-Bands, IEEE Trans. Compon. Packag. Manuf. Tech., 4 (2014), 1451–1460.

[20]Yamamoto, Y.; Li, K.; Hashimoto, O.: Tunable sharp notch filter for UWB application, Microw. Opt. Technol. Lett., 50 (2008), 2712—2715.

[21]Wei, F.; Chen, L.; Shi, X.; Liu, B.: Compact UWB bandpass filter with tunable notch band based on folded SIR, Electron. Lett., 47 (2011), 1229–1230.

[22]Cameron, R.: Advanced coupling matrix synthesis techniques for microwave filters, IEEE Trans. Microw. Theory Tech., 51 (2003), 1–10.
