A Compact, Tri-Band and 9-Shape Reconfigurable Antenna for WiFi, WiMAX and WLAN Applications

Full Text (PDF, 786KB), PP.45-53


Views:123   Downloads:10

Author(s)

Izaz Ali Shah, Shahzeb Hayat, Ihtesham Khan, Imtiaz. Alam, Sadiq Ullah, Adeel Afridi

Index Terms

Wi-Fi;WLAN;WiMAX;reconfigurable;monopole;single band;dual band;switches

Abstract

This paper introduces a novel 9-shaped multiband frequency reconfigurable monopole antenna for wireless applications, using 1.6 mm thicker FR4 substrate and a truncated metallic ground surface. The designed antenna performs in single and dual frequency modes depending on switching states. The antenna works in a single band (WiMAX at 3.5 GHz) when the switch is in the OFF state. The dual band frequency mode (Wi-Fi at 2.45 GHz and WLAN at 5.2 GHz) is obtained when the switch is turned ON. The directivities are: 2.13 dBi, 2.77 dBi and 3.99 dBi and efficiencies: 86%, 93.5% and 84.4% are attained at frequencies 2.45 GHz, 3.5 GHz and 5.2 GHz respectively. The proposed antenna has VSWR< 1.5 for all the three frequencies. The scattering and far-field parameters of the designed antenna are analyzed using computer simulation technology CST 2014. The performance of the proposed antenna is analyzed on the basis of VSWR, efficiency, gain, radiation pattern and return loss.

Cite This Paper

Izaz Ali Shah, Shahzeb Hayat, Ihtesham Khan, Imtiaz. Alam, Sadiq Ullah, Adeel Afridi,"A Compact, Tri-Band and 9-Shape Reconfigurable Antenna for WiFi, WiMAX and WLAN Applications",International Journal of Wireless and Microwave Technologies(IJWMT), Vol.6, No.5, pp.45-53, 2016.DOI: 10.5815/ijwmt.2016.05.05

Reference

[1]Ramadan, A., M. Al-Husseini, K. Y. Kabalan and A. EI-Hajj. Fractal-shaped reconfigurable antennas. INTECH Open Access Publisher, 2011; 1: 237-250.

[2]L. N. Pringle, P. H. Harms and S. P. Blalock. A reconfigurable aperture antenna based on switched links between electrically small metallic patches. IEEE Transactions on Antennas and Propagation, 2004, 52: 1434-144.

[3]Picasso: Flexible RF and Spectrum Slicing, http://steven-hong.com/Picasso.html, Accessed on 30 January 2016.

[4]M. R. Hamid, P. Gardner, P. S. Hall and F. Ghanem. Switched-band Vivaldi antenna. IEEE Transactions on Antennas and Propagation, 2011, 59:1472-1480.

[5]C. Wang, Z. H. Yan, P. Xu, J. B. Jiang and B. Li. Trident-shaped dual-band CPW-fed monopole antenna for PCS/WLAN applications. Electronics letters, 2011, 47:231-232.

[6]G. L. Xin and J. P. Xu. Wideband miniature G-shaped antenna for dual-band WLAN applications. Electronics Letters, 2007, 43: 1330-1332.

[7]H. F. AbuTarboush, R. Nilavalan, K. M. Nasar and H. S. Al-Raweshidy, D. Budimir. A reconfigurable H-shape antenna for wireless applications. IEEE Conference on Antennas and Propagation (EuCAP), 2010, 1-4.

[8]S. A. A. Shah, M. F. Khan, S. Ullah, and J. A. Flint. Design of a multi-band frequency reconfigurable planar monopole antenna using truncated ground plane for Wi-Fi, WLAN and WiMAX applications. IEEE International Conference on Open Source Systems and Technologies (ICOSST), 2014, 151-155.

[9]Z. Cui, Y. C. Jiao, L. Zhang and F. S. Zhang. The band‐notch function for a printed ultra‐wideband monopole antenna with E‐shaped slot. Microwave and Optical Technology Letters, 2008, 50 (8): 2048-2052.

[10]W. C. Liu and C. F. Hsu. Dual-band CPW-fed Y-shaped monopole antenna for PCS/WLAN application. Electronics Letters, vol. 41, no. 7, pp. 390-391, March. 2005.

[11]S. L. S. Yang, A. Kishk, and K. F. Lee. Frequency reconfigurable U-slot microstrip patch antenna. IEEE Antennas and Wireless Propagation Letters, 2008, 7: 127-129.

[12]S. V. Shynu., G. Augustin, C. K. Aadannan,.p. Mohanan. C-shaped slot loaded reconfigurable microstrip antenna. Electronics Letters, 2006, 42(6): 316-318.

[13]M. I. Lai, T. Y. Wu, J. C. Hsieh, C. H. Wang and S. K. Jeng. Design of reconfigurable antennas based on an L-shaped slot and PIN diodes for compact wireless devices. IET Microwaves, Antennas & Propagation, 2009, 3(1): 47-54.

[14]Y. L. Kuo, K. L. Wong. Printed double-T monopole antenna for 2.4/5.2 GHz dual-band WLAN operations. IEEE Transactions on Antennas and Propagation, 2003, 51(9): 2187-2192.

[15]J. R. Panda, R. S. Kshetrimayum. A printed F-shaped dual-band monopole antenna for RFID and WLAN applications. IEEE International Conference on Computer and Communication Technology (ICCCT), 2010, 789-791.

[16]Hayat Errifi, Abdennaceur Baghdad, Abdelmajid Badri, Aicha Sahel. "Radiation Characteristics Enhancement of Microstrip Triangular Patch Antenna using Several Array Structures." International Journal of Wireless and Microwave Technologies(IJWMT), Vol. 5, No. 3, pp. 1-17, May 2015. DOI: 10.5815/ijwmt.2015.03.01.

[17]Ali A. Saleh, Abdulkareem S. Abdullah. A Novel Design of Patch Antenna Loaded with Complementary Split-Ring Resonator and L- Shape Slot for (WiMAX/WLAN) Applications. International Journal of Wireless and Microwave Technologies(IJWMT), Vol. 4, No. 3, pp. 16-25, October 2014. DOI: 10.5815/ijwmt.2014.03.02.

[18]Idris IH, Hamid MR, Jamaluddin MH, Rahim MK, Kelly JR, Majid HA. Single-, Dual-and Triple-band Frequency Reconfigurable Antenna. Radioengineering. 2014; 23(3).

[19]C. A. Balanis. Antenna Theory, Analysis and Design. 2nd Ed., J. Wiley & Sons, New York, USA, 1997.

[20]Hirtenfelder F. Effective antenna simulations using CST MICROWAVE STUDIO®. In 2nd IEEE International ITG Conference on Antennas, 2007. INICA'07. 2007, 239-239.
