IJWMT Vol.6, No.5, Sep. 2016

A Compact Multiband U Shape MIMO Antenna for Wireless Application

Full Text (PDF, 703KB), PP.61-71


Views:79   Downloads:1

Author(s)

Sachin S. Khade, S.L.Badjate

Index Terms

Defective ground structure (DGS);Ground plane (GP);Multiple-input multiple output (MIMO) antenna;phone antenna;Voltage standing wave ratio (VSWR)

Abstract

A compact multiple-input-multiple-output (MIMO) antenna with two dual-branch U shape monopoles is proposed. The isolation between two antenna element is improve by adding three dumbbell shaped DGS between them. This antenna provides multiple frequency bands i.e. 2.4/5.8-GHz for WLAN, 2.5/3.5/5.5-GHz for WiMAX and 3.1–4.8 GHz for lower UWB band operation. The Antenna provides good results with Reflection coefficients < -15 dB and Transmission Coefficients < -30 dB. The results shows that the MIMO antenna can be serve as a phone antenna and it is suitable for integration within portable devices and handheld terminals with total maximum gain up to 4.5 dB and by combining all fields it provides total maximum gain up to 3.2 dBi.

Cite This Paper

Sachin S. Khade, S.L.Badjate,"A Compact Multiband U Shape MIMO Antenna for Wireless Application",International Journal of Wireless and Microwave Technologies(IJWMT), Vol.6, No.5, pp.61-71, 2016.DOI: 10.5815/ijwmt.2016.05.07

Reference

[1]Jian-Feng Li, Qing-Xin Chu, and Tian-Gui Huang,"A Compact Wideband MIMO Antenna With Two Novel Bent Slits," IEEE Trans. on antennas and propagation, vol. 60, no. 2, Feb 2012.

[2]Mohammad S. Sharawi, Ahmed B. Numan, Muhammad U. Khan, and Daniel N. Aloi, "A Dual-Element Dual-Band MIMO Antenna System with Enhanced Isolation for Mobile Terminals," IEEE antennas and wireless propagation letters, Vol. 11, 2012.

[3]Xiang Zhou, XuLin Quan, and RongLin Li, Senior Member, IEEE, "A Dual-Broadband MIMO Antenna System for GSM/UMTS/LTE and WLAN Handsets," IEEE antennas and wireless propagation letters, Vol. 11, 2012

[4]Jian-Feng Li and Qing-Xin Chu, "Tri-Band Antenna with Compact Conventional Phone Antenna and Wideband MIMO Antenna," IEEE 2012.

[5]Zhengyi Li, Zhengwei Du, and Ke Gong, "A Dual-slot Diversity Antenna with Isolation Enhancement Using Parasitic Elements for Mobile Handsets," IEEE 2009.

[6]Chun-Xu Mao, Qing-Xin Chu, "Compact Co-Radiator UWB-MIMO Antenna with Dual Polarization," IEEE 2013.

[7]Muhammad U. Khan and Mohammad S. Sharawi, Ashley Steffes and Daniel N. Aloi,"A 4-element MIMO Antenna System Loaded with CSRRs and Patch Antenna Elements" IEEE 2013.

[8]Jian-Feng Li, Qing-Xin Chu, Senior Member, IEEE, Zhi-Hui Li, and Xing-Xing Xia "Compact Dual Band-Notched UWB MIMO Antenna With High Isolation", IEEE Transaction on antennas and propagation, Vol. 61, no. 9, September 2013.

[9]Yuan Ding, Zhengwei Du, Ke Gong, and Zhenghe Feng, "A Novel Dual-Band Printed Diversity Antenna for Mobile Terminals", IEEE Trans. on analysis and propagation, Vol. 55, NO. 7, july 2007

[10]L. Liu, S. W. Cheung, T. I. Yuk and D. Wu, "A Compact Ultra wideband MIMO Antenna", 7th European Conference on Antennas and Propagation (EuCAP) 2013.

[11]Muhammad U. Khan, Mohammad S. Sharawi , Daniel N. Aloi, "A multi-band 2×1 MIMO antenna system consisting of CSRR loaded patch elements", IEEE 2013.

[12]A.A. Zekry A.A. Asaker , R.S. Ghoname "Design of a Planar MIMO Antenna for LTE-Advanced"International Journal of Computer Applications (0975 – 8887) Volume 115 – No. 12, April 2015

[13]Cho-Jung Lee, #Lih-Tyng Hwang, T.-S. Jason Horng, Shun-Min Wang, Yi-Chieh Lin, and Kun-Hui Lin, "A MIMO Antenna with Built-In Isolation for WLAN USB Dongle Applications" Asia-Pacific Microwave Conference Proceedings,2013.

[14]Henridass Arun, Aswathy K. Sarma, Malathi Kanagasabai,,"Deployment of Modified Serpentine Structure for Mutual Coupling Reduction in MIMO Antennas"IEEE antennas and wireless propagation letters, vol. 13, 2014.

[15]Hayat Errifi, Abdennaceur Baghdad, Abdelmajid Badri, Aicha Sahel, " Radiation Characteristics Enhancement of Microstrip Triangular Patch Antenna using Several Array Structures", International Journal Wireless and Microwave Technologies, 2015.
